Split-assembly frame
The assembled frame stands on braked swivel casters without a dedicated runway rail.
Supplied Portable Mobile Gantry Crane image 1. Model, rating and image-use rights remain to be verified.
Gantry Crane / crane detail review
Portable Mobile Gantry Crane
A freestanding assembled gantry with braked casters for temporary workshop lifting.
- Lifting Capacity
- 0.25 - 10t(customizable)
- Span
- 2 - 12m(non‑standard span available)
Source family ranges — exact configuration pending.
Source headline: 3 Ton Easy‑assembly Portable Mobile Gantry Crane with Brake Casters. The full source table is a family / option range, not the specification of one selected unit. Model, drawing and test evidence remain pending.
overview
What this equipment is designed to do.
A freestanding assembled gantry with braked casters for temporary workshop lifting.
The assembled frame stands on braked swivel casters without a dedicated runway rail.
The source describes bolted assembly and adjustable height / span. Final adjustment ranges and locking arrangements require a manual.
Manual trolley and electric hoist choices are listed. The floor, caster loading and loaded-travel rules must be verified.
The table below preserves every supplied parameter row. Exact model association, drawings and test evidence remain open; source family maxima must not be combined into an assumed build.
structure
Structure & installation interfaces.
Braked swivel-caster base
The source describes bolted assembly and adjustable height / span. Final adjustment ranges and locking arrangements require a manual.
Manual trolley or electric hoist
Manual trolley and electric hoist choices are listed. The floor, caster loading and loaded-travel rules must be verified.
Engineering drawings pending
No approved dimensions, interface drawing, load reaction, wiring diagram or downloadable engineering file was supplied. Request the selected model and site-specific drawing before installation.
specifications
Capacity, geometry & control data.
Supplied technical table, transcribed without selecting a model. Ranges and options must not be combined into an assumed build.
| Parameter | Source value / pending evidence | Selection boundary |
|---|---|---|
| Lifting Capacity | 0.25 - 10t(customizable) | Source family data; exact model and conditions pending. |
| Span | 2 - 12m(non‑standard span available) | Source family data; exact model and conditions pending. |
| Lifting Height | 1 - 6m(customizable) | Source family data; exact model and conditions pending. |
| Working Duty | A1 - A4 | Source family data; exact model and conditions pending. |
| Control Method | Manual pull / Wireless remote control / Pendant control | Source family data; exact model and conditions pending. |
| Lifting Mechanism | Manual trolley / Electric hoist | Source family data; exact model and conditions pending. |
| Power Supply | 380V/50Hz/3‑phase(220V/440V/60Hz customizable) | Source family data; exact model and conditions pending. |
| Certification | Pending evidence — source lists CE, ISO 9001 | No certificate file or model coverage supplied; no certification is asserted. |
| Caster Type | Brake‑equipped swivel casters, Electric travelling casters | Source family data; exact model and conditions pending. |
| Material | Q235B/Q355B carbon steel | Source family data; exact model and conditions pending. |
performance
Operating conditions & unverified limits.
The supplied material describes configuration options but does not include measured performance curves, a test method or an independently documented operating envelope.
- The listed duty, load and geometry ranges require a selected configuration and load spectrum; no load-test or engineering calculation was supplied.
- Source references to certification, full testing, reliability, price, export delivery and special-environment protection are not verified credentials or contractual commitments.
- A mobile design does not establish permission to travel with a suspended load. Ground bearing capacity, operating position, brakes / restraints and loaded-travel rules need the model manual.
Test and performance evidence pending
No fabricated load curve, motor-power chart, noise result or safety rating has been drawn for this preview. Provide model-specific test conditions and reports.
applications
Source-described application contexts.
Machine-tool, motor and gearbox maintenance
Machine tools, motors and gearboxes are identified for temporary workshop overhaul.
Intermittent small-factory lifting
The source describes intermittent lifting at changing small-factory work positions.
Temporary warehouse cargo handling
Moulds, spare parts and light machinery are described for temporary warehouse handling.
Laboratory and test-bench assembly
Laboratory units and test equipment are identified as assembly loads; no positioning tolerance is supplied.
These are application descriptions, not verified customer projects or delivered equipment references.
features
Configuration & selection considerations.
Adjustable span and height
The supplied copy lists adjustable span and height. The assembled frame stands on braked swivel casters without a dedicated runway rail.
Manual movement and caster options
The supplied copy lists manual movement and caster options. The source describes bolted assembly and adjustable height / span. Final adjustment ranges and locking arrangements require a manual.
Manual chain block / electric hoist
The supplied copy lists manual chain block / electric hoist. Manual trolley and electric hoist choices are listed. The floor, caster loading and loaded-travel rules must be verified.
Steel frame and optional aluminium version
The supplied copy lists steel frame and optional aluminium version. Manual trolley and electric hoist choices are listed. The floor, caster loading and loaded-travel rules must be verified.
compatibility
Check the interfaces before selection.
Use the actual load, geometry, support structure, duty cycle, power supply, control scheme and environment to review suitability. No universal fit or suitability is assumed.
Source headline: 3 Ton Easy‑assembly Portable Mobile Gantry Crane with Brake Casters. The full source table is a family / option range, not the specification of one selected unit. Model, drawing and test evidence remain pending.
proof
Certificates, drawings & project evidence.
Proof, downloads and video pending
No model certificate, test file, genuine delivery case, authorised customer reference, engineering download or product video was supplied. Source marketing mentions of certification or full testing are not displayed as verified credentials.
service
Technical support & order boundaries.
The supplied service description covers equipment selection discussions, customised drawing requirements, installation / operation documentation, procurement assistance and remote troubleshooting.
Document availability, OEM / ODM scope, inspection, delivery, installation, warranty, acceptance and after-sales obligations must be agreed for the selected product. No fixed lead time, price, stock or performance promise is added.
faq
Before requesting a quotation.
Which data should accompany an enquiry?
Provide load, span or outreach, lifting height, power supply, duty, environment and destination. Replacement parts also require the existing model and interfaces.
Are source ranges certified for every image?
No. Source values describe families and options. Exact model association, calculations, tests and certificates remain pending.
What are the lead time and warranty?
No confirmed terms have been supplied. Agree timing, price, warranty and service responsibilities for the selected configuration.
Is installation included?
Installation documents and remote technical support are described in source material. On-site work, commissioning and acceptance responsibilities remain to be agreed.
