Suspended main girder
The suspended bridge travels on the bottom flange of an overhead runway. Its supporting roof / beam connection must be assessed.
Supplied Underhung Overhead Crane image 1. Model, rating and image-use rights remain to be verified.
Overhead Crane / crane detail review
Underhung Overhead Crane
Underhung equipment travelling on the lower flange of a supporting runway.
- Lifting Capacity
- 0.5t - 10t (customizable)
- Span
- 3m - 22.5m (non‑standard span available)
Source family ranges — exact configuration pending.
Source headline: 5 Ton Low Headroom Underhung Overhead Crane for Workshop. The full source table is a family / option range, not the specification of one selected unit. Model, drawing and test evidence remain pending.
overview
What this equipment is designed to do.
Underhung equipment travelling on the lower flange of a supporting runway.
The suspended bridge travels on the bottom flange of an overhead runway. Its supporting roof / beam connection must be assessed.
CD1 / MD1 hoisting is listed in the table; European hoist and VFD options are also discussed in copy.
The layout avoids a floor-mounted pillar, but the material does not establish that any existing roof is adequate without modification.
The table below preserves every supplied parameter row. Exact model association, drawings and test evidence remain open; source family maxima must not be combined into an assumed build.
structure
Structure & installation interfaces.
Bottom-flange runway travel
CD1 / MD1 hoisting is listed in the table; European hoist and VFD options are also discussed in copy.
Electric hoist and building connections
The layout avoids a floor-mounted pillar, but the material does not establish that any existing roof is adequate without modification.
Engineering drawings pending
No approved dimensions, interface drawing, load reaction, wiring diagram or downloadable engineering file was supplied. Request the selected model and site-specific drawing before installation.
specifications
Capacity, geometry & control data.
Supplied technical table, transcribed without selecting a model. Ranges and options must not be combined into an assumed build.
| Parameter | Source value / pending evidence | Selection boundary |
|---|---|---|
| Lifting Capacity | 0.5t - 10t (customizable) | Source family data; exact model and conditions pending. |
| Span | 3m - 22.5m (non‑standard span available) | Source family data; exact model and conditions pending. |
| Lifting Height | 6m – 30m (customizable) | Source family data; exact model and conditions pending. |
| Working Duty | A3 - A5 | Source family data; exact model and conditions pending. |
| Control Method | Cabin control / Wireless remote control / Pendant control | Source family data; exact model and conditions pending. |
| Lifting Mechanism | Electric hoist (CD1 / MD1) | Source family data; exact model and conditions pending. |
| Power Supply | 380V/50Hz/3‑phase (220V/440V/60Hz customizable) | Source family data; exact model and conditions pending. |
| Ambient Temperature | -25℃ ~ 40℃ | Source family data; exact model and conditions pending. |
| Certification | Pending evidence — source lists CE, ISO 9001 | No certificate file or model coverage supplied; no certification is asserted. |
| Optional Configuration | Overload protection, Travel limit switch, Buffer device | Source family data; exact model and conditions pending. |
performance
Operating conditions & unverified limits.
The supplied material describes configuration options but does not include measured performance curves, a test method or an independently documented operating envelope.
- The listed duty, load and geometry ranges require a selected configuration and load spectrum; no load-test or engineering calculation was supplied.
- Source references to certification, full testing, reliability, price, export delivery and special-environment protection are not verified credentials or contractual commitments.
Test and performance evidence pending
No fabricated load curve, motor-power chart, noise result or safety rating has been drawn for this preview. Provide model-specific test conditions and reports.
applications
Source-described application contexts.
Low-ceiling legacy workshops
Legacy workshops are described for tooling and component lifting under restricted ceilings.
Warehouse storage aisles
Pallet and semi-finished goods are identified in warehouse aisles; check overhead clearances and traffic separation.
Vehicle and equipment service bays
Transmission removal and component fitting are described in low-clearance service bays.
Food and beverage production contexts
Food and beverage contexts are mentioned; no hygiene, washdown or clean-room certification is supplied.
These are application descriptions, not verified customer projects or delivered equipment references.
features
Configuration & selection considerations.
Runway and building assessment
The supplied copy lists runway and building assessment. The suspended bridge travels on the bottom flange of an overhead runway. Its supporting roof / beam connection must be assessed.
Pendant or remote control
The supplied copy lists pendant or remote control. CD1 / MD1 hoisting is listed in the table; European hoist and VFD options are also discussed in copy.
European hoist / VFD options
The supplied copy lists european hoist / vfd options. The layout avoids a floor-mounted pillar, but the material does not establish that any existing roof is adequate without modification.
Anti-derailment and travel protection
The supplied copy lists anti-derailment and travel protection. The layout avoids a floor-mounted pillar, but the material does not establish that any existing roof is adequate without modification.
compatibility
Check the interfaces before selection.
Use the actual load, geometry, support structure, duty cycle, power supply, control scheme and environment to review suitability. No universal fit or suitability is assumed.
Source headline: 5 Ton Low Headroom Underhung Overhead Crane for Workshop. The full source table is a family / option range, not the specification of one selected unit. Model, drawing and test evidence remain pending.
proof
Certificates, drawings & project evidence.
Proof, downloads and video pending
No model certificate, test file, genuine delivery case, authorised customer reference, engineering download or product video was supplied. Source marketing mentions of certification or full testing are not displayed as verified credentials.
service
Technical support & order boundaries.
The supplied service description covers equipment selection discussions, customised drawing requirements, installation / operation documentation, procurement assistance and remote troubleshooting.
Document availability, OEM / ODM scope, inspection, delivery, installation, warranty, acceptance and after-sales obligations must be agreed for the selected product. No fixed lead time, price, stock or performance promise is added.
faq
Before requesting a quotation.
Which data should accompany an enquiry?
Provide load, span or outreach, lifting height, power supply, duty, environment and destination. Replacement parts also require the existing model and interfaces.
Are source ranges certified for every image?
No. Source values describe families and options. Exact model association, calculations, tests and certificates remain pending.
What are the lead time and warranty?
No confirmed terms have been supplied. Agree timing, price, warranty and service responsibilities for the selected configuration.
Is installation included?
Installation documents and remote technical support are described in source material. On-site work, commissioning and acceptance responsibilities remain to be agreed.
